Aten Splitter, HDMI, 10 Port - VS0110HA
• HDMI (3D, Deep colour, 4K); HDCP 1.4 compliant
• Superior video quality – up to 4K resolutions (4096 x 2160 @ 60Hz; 4:2:0)
• Long distance transmission from source to output - up to 15 m
• Built-in bi-directional RS-232 serial control port for high-end system control
The VS0110HA 4K HDMI Splitter is a perfect solution for applications that require sending one source of high-definition 4K video to ten displays at the same time. The HDMI interface caters to most mainstream sources and sinks, such as DVD players, satellite set-top boxes, and any HDMI displays. Featuring ATEN EDID technology, the VS0110HA guarantees continuous EDID communication with connected devices and maintains optimum video outputs.
The VS0110HA 4K HDMI Splitter is HDCP (High-bandwidth Digital Content Protection) compliant, making it effective for use with all HDMI displays in home theatre applications, as well as in corporate, educational and commercial settings.
Package Contents
1x VS0110HA 10-Port 4K HDMI Splitter
1x Power Adapter
1x Mounting Kit
1x User Instructions
|
LEDs |
|
|
Power |
1 x LED (Green) |
|
Input |
1 x LED (Green) |
|
Video Output |
10 x LED (Green) |
|
Video Input |
|
|
Interfaces |
1 x HDMI Type A Female (Black) |
|
Impedance |
100 Ω |
|
Max. Distance |
5m (at 4K resolution) |
|
Video Output |
|
|
Interfaces |
10 x HDMI Type A Female (Black) |
|
Impedance |
100 Ω |
|
Max. Distance |
10m (at 4K resolution) |
|
Video |
|
|
Max. Data Rate |
10.2 Gbps (3.4 Gbps Per Lane) |
|
Max. Pixel Clock |
340 MHz |
|
Compliance |
HDMI 1.4 (3D, Deep Colour, 4K); |
|
Max. Resolution |
Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); |
|
Control |
|
|
RS-232 |
Connector: 1 x DB-9 Female (Black) |
|
EDID Settings |
EDID Switch x1 |
|
Connectors |
|
|
Power |
1 x DC Jack |
|
USB Port |
1 x Micro USB (FW upgrade) |
|
Power Consumption |
DC5V:4.34W:20BTU |
|
Environmental |
|
|
Operating Temperature |
0 - 40 °C |
|
Storage Temperature |
-20 - 60 °C |
|
Humidity |
0 - 80% RH, Non-Condensing |
|
Physical Properties |
|
|
Housing |
Metal |
|
Weight |
2.10 kg ( 4.63 lb ) |
|
Dimensions (L x W x H) |
43.72 x 15.78 x 4.40 cm |
|
Carton Lot |
3 pcs |
|
Note |
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
