Aten Matrix Switch, HDMI, 4 Port, with Scaler - VM6404HB

True 4K Pro AV solutions with High Dynamic Range (HDR) technology is the trend of high-definition video that delivers the ultimate visual experience with exceptional sharp and vibrant video quality. ATEN’s VM6404HB True 4K HDMI Matrix Switch with Scaler is compatible with the latest True 4K video resolutions of 4096 x 2160 / 3840 x 2160@60Hz (4:4:4) and HDR, guaranteeing crystal-clear images across four displays.

The VM6404HB supports 4K@60Hz, HDMI 2.0, and HDCP 2.2 and features Seamless Switch™ that employs an FPGA matrix architecture that ensures continuous video streams, real-time control, and stable signal transmissions. With a built-in high-performance scaler, the VM6404HB easily converts various input resolutions into various output display resolutions, giving viewers the best video and picture quality across all displays. The switch integrates video wall functionality with an easy-to-use web GUI that lets you create 8 connection profiles that can be customized into different video wall layouts.

The VM6404HB is an ideal solution for applications that require multiple HDMI displays with multiple HDMI sources to be conveniently set up – such as for stage presentations, digital classroom, video conference rooms, and any installation that requires real-time synchronization.

• Package Contents

1x VM6404HB 4 x 4 True 4K HDMI Matrix Switch with Scaler

1x LIN2-418K-E12G Power Cord

1x 2XRT-0106G IR Remote Control

1x 2XRT-0003G IR Receiver

1x KC06-0012-B07G Mounting Kit

1x User Instructions

• Features:

4 x 4 HDMI input/output connections

Multiple Control Methods – system management via front-panel pushbuttons, IR, RS-232 control, and Ethernet connection for web GUI or Telnet

View and control via ATEN Video Matrix Control App in a swift and agile way

True 4K Resolutions –handles uncompressed video resolutions up to 4096 x 2160 / 3840 x 2160@60Hz (4:4:4)

4K Scaler –features a 4K video scaler to convert input resolutions to the optimum display resolutions

Seamless Switch™ –features close-to-zero second switching for continuous video streams, real-time switching, and stable signal transmissions*

Video Wall –allows you to create custom video wall layouts via intuitive web GUI*

True 4K EDID Expert –selects optimum EDID settings for smooth power-up, high-quality display, and use of the best resolutions across different screens

FrameSync –prevents image tearing by synchronizing the scaler output frame rate to the input signal frame rate

Audio-enabled – HDMI audio can be extracted to stereo audio

HDMI (3D, Deep colour, 4K); HDCP 2.2 compatible

Consumer Electronics Control (CEC) support

ESD protection for HDMI

Rack-mountable (1U design)
