Hisense Sound Bar, Bluetooth, 600W 5.1 Channel with Wireless Subwoofer - AX5140Q
• 5.1.4 Multi Channel
• Hi-Concerto
• Room Fitting Tuning
• True Wireless Rear Surround Speakers
• Game Pro
• EzPlay 3.0
• ConnectLife APP
• AI EQ Mode
Discover the immersive audio experience of the Hisense AX5140Q 5.1.4CH Soundbar with Wireless Subwoofer. This user manual provides detailed instructions for setup, operation, and troubleshooting.
Explore features like Dolby Atmos and DTS:X for a cinematic soundstage, seamless Bluetooth connectivity, and Roku TV Ready integration.
Learn how to connect your soundbar via HDMI, Optical, or AUX, and optimize your audio settings for movies, music, and gaming.
For detailed safety instructions, placement and mounting guides, and advanced features like Hi-Concerto and EzPlay, refer to the comprehensive sections within this manual.
Key Features:
5.1.4 Channel Surround Sound
Wireless Subwoofer
Dolby Atmos & DTS:X Support
Bluetooth Connectivity
Roku TV Ready
Multiple Connectivity Options (HDMI, Optical, AUX, USB)
Brand Hisense
Model AX5140Q
Soundbar
Power Supply 100-240V~ 50/60Hz
Power Consumption 40W
< 0.5 W (StandBy)
USB
5V 500mA
USB (2.0) / FAT32 / FAT16
32G (max) , WAV / WMA / MP3 / FLAC.
Dimension (WxHxD) 1020 x 59 x 108 mm / 40.1" x 2.3" x 4.2"
Net weight 2.7 kg / 5.95 lbs
Audio input sensitivity 500mV
Frequency Response 120Hz - 20KHz
Operating Temperature 0°C - 45°C
Subwoofer
Power Supply 100-240V~ 50/60Hz
Power Consumption 40W
< 0.5 W (StandBy)
Dimension (WxHxD) 163 x 338 x 335 mm / 6.4" x 13.3" x 13.1"
Net weight 5.6 kg / 12.3 lbs
Frequency Response 40Hz-150Hz
Surround Speaker
Adapter Mode
- Input
- Output
DK42C-240-1500
100-240V~ 50/60Hz 1.0A
24V 1.5A
Frequency Response 180Hz - 20KHz
Dimension (WxHxD) 100 x 202 x 119 mm / 3.9" x 7.9" x 4.7"
Net weight 1.4 kg (0.7 kg x 2) / 3.1 lbs (1.55 lbs x 2)
Wireless Specification (EU)
Bluetooth version / profiles
Bluetooth frequency range
Bluetooth Max. transmitting power
V 5.3 (A2DP, AVRCP)
2400 MHz ~ 2483.5 MHz
≤ 10 dBm
Wireless frequency range
Max. transmitting power 5.8G: 5729-5848 MHz / ≤10 dBm
Modulation Type GFSK, π/4 DQPSK, 8-DPSK
Remote Control
Distance/Angle 19.7 feet (6m) / 30°
Battery type AAA (1.5V x 2)
AX5140Q Datasheet PDF
