Wolfvision Wireless Presentation System - CYNAPPUREMI
• Entry-level wireless screen sharing
• Entry-level simple BYOD wireless screen sharing - ideal for smaller classrooms, meeting rooms and huddle spaces everywhere.
• BYOD wireless screen sharing
• No apps, no dongles, no extra software needed
• 4K UHD output resolution
• Easy-to use user interface
• Room management APIs
• Peripheral device control
• Enterprise level security
No apps, no buttons, no cables, no hassle
Cynap Pure Mini supports AirPlay, Miracast, and Chromecast screen mirroring, so no apps, buttons, dongles, or extra software are needed when sharing content on-screen from any smartphone, laptop, or tablet
Enterprise level security
Network security is a key consideration, and our custom-built, closed, Linux system offers 100% wireless data encryption, IEEE802.1x authentication, plus customizable security features to give you exactly the level of protection you require.
Cynap Pure Mini supports AirPlay, Miracast, and Chromecast screen mirroring, so no apps, buttons, dongles, or extra software are needed when sharing content on-screen from any smartphone, laptop, or tablet.
Network security is a key consideration, and our custom-built, closed, Linux system offers 100% wireless data encryption, IEEE802.1x authentication, plus customisable security features to give you exactly the level of protection you require.
Cynap Pure Mini can be set up and used immediately. Settings are easy to configure, and you'll be up and running in no time at all!
Free firmware, no license fees
Regular firmware updates provide you with new features and improvements, helping to extend the life of your investment, and maximise your ROI.
Remote management & administration
The vSolution Link Pro software is available free of charge and enables easy remote setup, monitoring, management and updating of multiple systems in different locations.
This model is ideal for smaller classrooms, meeting rooms and huddle spaces.
- Simple BYOD wireless screen sharing
- No apps, no dongles, no extra software needed
- 4K UHD output resolution
- Easy-to use user interface
|
Features
|
Cynap Pure Mini |
|
Operating system
|
Linux |
|
Output resolution
|
2160p60/30, 1080p60/30, 720p60 |
|
Supported devices for wireless mirroring (up to 4K depending on device)
|
iOS, iPadOS, Android, Windows, macOS, Chrome OS |
|
Supported mirroring protocols |
AirPlay, Miracast (Peer-to-Peer and MICE), Chromecast, vSolution Cast
|
|
Max. no. of on-screen windows
|
4 |
|
Touchback functionality
|
Yes, for Windows (Miracast & vSolution Cast) |
|
vSolution Link Pro software for remote management & firmware updates
|
Yes |
|
Inputs/Outputs
|
HDMI Out x1, Front USB x2, 1x 1GigE LAN port |
|
Audio
|
Via HDMI out, USB |
|
Bluetooth device discovery
|
Yes |
|
Wifi standards (Wi-Fi 5)
|
2.4 GHz in Access Point Mode / 2.4 and 5 GHz in Infrastructure Mode
|
|
Network protocols |
TCP/IP, HTTP, HTTPS, SNTP/NTP, SSL, SSH, UDP
|
|
IP configuration |
DHCP, Static (IP address, Subnet mask, Default gateway, DNS server), Proxy, Interface priority
|
|
Security authentication for LAN |
IEEE 802.1X
|
|
Security encryption for wireless WLAN |
WEP, WPA2, WPA2 Enterprise or IEEE 802.1X |
|
External controlling |
Multi-touch display, web interface, room control system, keyboard/mouse, optional remote control
|
|
Peripheral device control
|
Yes |
|
Dimensions (L x W x H)
|
70 x 70 x 35 mm (2.76 x 2.76 x 1.37“) |
|
Power consumption
|
24W |
|
Weight
|
260g (0.57lb) |
|
Optional accessories
|
Optional remote control |
|
Included accessories
|
Power supply, VESA mount |
|
Limited warranty |
3 years (optional warranty extension up to 5 years)
|
